Bianchi T-Tronik T Type

by Bianchi

BIANCHI T-TRONIK T-TYPE ELECTRIC HYBRID BIKE 2022

The Bianchi T-Tronik C-Type brings together simplicity, functionality and style, and is designed for touring, be that on road, gravel or trails. The Shimano E6100 250W motor offers 60Nm of torque and is paired with a 417Wh Phylion integrated battery to deliver a boost for up to 60 miles. There are three settings so you can dial in assistance to suit the ride or your energy levels.

The frame is constructed from strong alloy while a 63mm travel Suntour fork effectively soaks up shock for more comfort in the saddle. A SunRace drivetrain with 9 gears in a 1x configuration provides the range for both climbs and descents and hydraulic discs take care of braking, working well in both wet and dry conditions. Kitted out with front and rear lights, mudguards, a kickstand and a Racktime rear carrier, you can get to your destination safe and dry, and carrying all the kit you need.

TECHNICAL SPECIFICATION

Frame	Bianchi T-Tronik T-Type Frame 28" Tourer, suspended fork geometry, alu PG 6061 32/37 Max shell, disc brake, O.L.D.135mm, D/T battery, size
Fork	Suntour SF15-NEX-E25-DS-700C-63 post mount disc brake, 1.1/8", travel 63mm, compatible with mudguard, OLD 100mm, quick release type
Headset	FSA 1.1/8" 44H-N10P
Bottom Bracket	Included with motor unit
Stem	Velomann, 28.6mm steerer ID clamp, 31.8mm
Handlebar	Velomann 31.8mm, 680mm width, 20mm rise, 15° sweep
Grips	Herrmans GRIPset Oxy DD29BR/BL 130mm/130mm black-black, 22mm diameter
Front Brake	Radius BH-M960, 900mm hose length, direct mount with adapter, Radius rotor RT900, 160mm, Center Lock
Rear Brake	Radius BH-M960, 1700mm hose length, direct mount, with J-kit, with adapter, Radius rotor RT900, 160mm, Center Lock
Brake Levers	Radius, hydraulic
Rear Derailleur	SunRace, 9-speed, maximum 42T
Shift Levers	SunRace DLE903N, 9-speed, with optical gear
Chain	KMC e9s EPT, 9-speed
Cassette	SunRace, 9-speed
Crankset	Shimano FC-E6100, 170mm crank length, 38T, for chain line 46.5mm
Front Wheel	Velomann 29", 23-622, 32-hole black
Rear Wheel	Velomann 29", 23-622, 32-hole black
Front Tyre	Chaoyang E-Liner City 700x45c, 60tpi, clincher
Rear Tyre	Chaoyang E-Liner City 700x45c, 60tpi, clincher
Saddle	Selle Royal, Essenza
Seatpost	Velomann, length 350mm, diameter 31,6mm, Al2014 shaft and alloy head
Pedals	included
Accessories	SKS Mudguard profile A60S, internal cable routing on the rear mudguard, secuclip/esc clip, protector on front and rear tail, protector on front mudguard / Ursus R81 WAVE REAR, 28" kickstand, 40mm fixing plate (load 35kg) / Racktime rear carrier, RT Eco 2.0, 28", black with round stay 350mm / Herrmans Mr GO front light / Axa Juno rear light
Range	60 miles (depending on rider weight, conditions and assist level)
Motor	Shimano E6100 250W, torque 60Nm
Battery	417Wh Phylion integrated battery
